LT-4000
FEATURES
The Acudor LT-4000 is a lightweight aluminum, specialty access door for walls and ceilings.
- All aluminum construction is ideal for exteri
ADDITIONAL INFORMATION
Material: Aluminum
Door: .064”, flush to edge of frame, 1-5/16” mitered aluminum extrusion flange
Mounting Frame: .080“, 1-1/2” deep
Hinge: Doors with width 24” or less to have concealed pin hinge. Doors with width over 24” to have continuous aluminum piano hinge with exposed knuckle, set to open to 180 degrees.
Gasket: 1/8” x 3/8” Closed Cell Neoprene Gasketing
Standard Latch: Screwdriver Operated Cam Latch
Optional Latches/Locks: Cylinder lock & key
Finish: Mill Finish
Files to download
Last Modified: 2025-04-23
Share
Specifications
| SKU / Part # | Product Name | Inches (MM) | Price | QTY | Add to Cart |
|---|---|---|---|---|---|
| Special Order | LT-4000 | 8 x 8 (203 x 203) |
---
|
|
|
| Special Order | LT-4000 | 10 x 10 (254 X 254) |
---
|
|
|
| Special Order | LT-4000 | 12 x 12 (305 X 305) |
---
|
|
|
| Special Order | LT-4000 | 14 x 14 (356 X 356) |
---
|
|
|
| Special Order | LT-4000 | 16 x 16 (406 X 406) |
---
|
|
|
| Special Order | LT-4000 | 18 x 18 (457 X 457) |
---
|
|
|
| Special Order | LT-4000 | 24 x 24 (610 X 610) |
---
|
|
|
| Special Order | LT-4000 | 24 x 36 (610 X 914) |
---
|
|
|
| Special Order | LT-4000 | 24 x 48 (610 X 1220) |
---
|
|
|
| Special Order | LT-4000 | 30 x 30 (762 X 762) |
---
|
|
|
| Special Order | LT-4000 | 36 x 36 (914 X 914) |
---
|
|
|
| Special Order | LT-4000 | 36 x 48 (914 X 1220) |
---
|
|
|
| Special Order | LT-4000 | 48 x 48 (1220 X 1220) |
---
|
|
|
| Special Order | LT-4000 | 60 x 48 (1524 x 1220) |
---
|
|
|
| Special Order | LT-4000 | 72 x 48 (1829 x 1220) |
---
|
|
